Maxi Lime

Designed for larger units & humid environments, the ‘all-in-one system’ Maxi Lime elbow pump gives you supreme power when needed. (‘Pump only pack’ also available).

Max. flow

35L/h


Max. rec. head

15m (flow rate 10L/h)


Sound level

35dB(A) @ 1m

Maxi Lime, FP2213

Maxi Lime, FP2213

Maxi Lime – in the box

In the box

Maxi Lime, FP2213

Maxi Lime BBJ (Airco)

The Maxi Lime sits in the trunking elbow. Perfect for commercial use and retrofit installs.

The Maxi Lime sits in the trunking elbow. Perfect for commercial use and retrofit installs.

Mini Pump Install

Maxi Lime, FP2213

Maxi Lime, FP2213

Maxi Lime – in the box

In the box

Maxi Lime, FP2213

Maxi Lime BBJ (Airco)

The Maxi Lime sits in the trunking elbow. Perfect for commercial use and retrofit installs.

The Maxi Lime sits in the trunking elbow. Perfect for commercial use and retrofit installs.

Mini Pump Install

    Part number Colour Description
    FP2213 Ivory BBJ (Airco)
    FP2215 Maxi Lime Replacement
    • Sits in trunking elbow
    • Left or right install
    • Range of trunking systems
    • Easy access for servicing
    • Up to 46kW / 157,000Btu/h
    • Large commercial AC units; High wall split systems
    • Perfect for... Large commercial high wall split units
    Data Based
    @ 230 VAC 50Hz
    Max. flow
    35L/h
    Max. rec. head
    15m
    dB(A)
    35
    Power supply
    230 VAC, 0.11A, 16W, 50/60Hz
    Rated
    Non continuous
    Class
    II appliance
    Max. unit output
    46kW / 157,000Btu/h
    Max. water temp
    40°C / 104°F
    Discharge tube
    6mm ID
    IP Protection
    IP24
    Safety switch
    3.0A Normally closed
    Thermal protection
    1
    Fully potted
    1
    Self priming
    1
    Flow Chart
    • Maxi Lime pump (inc. 750mm discharge tube with 6mm ID connector and 1.5m hard wired power cable)
    • 500mm Lime green inlet hose 14mm ID
    • 40mm Vinyl breather tube 6mm ID
    • Anti siphon device
    • Elbow front and back
    • 800mm conduit front and back
    • Gasket (BBJ and Inoac/Inaba systems only)
    • Ceiling plate
    • Drain connector kit
    • Fixing kit Install manual
